產品介紹
| Fan = DC-Fan | Size = 60x60x20 | Speed = | Flow = | Noise = |
| Bearing type: ◎=Ball ※=Sleeve ●=Hypro Bearing | |||||||||
| Frame Size | Model No | Bearing | Volt. (VAC) | Current (A) | Speed (rpm) | Air Flow (CFM) | Pressure (InAq) | Noise (dB/A) | |
| 60x60x20(ag) | AG06012DB207300 | ◎● | 12 | 0.16 | 4000 | 19.753 | 0.170 | 31.8 |  |
| 60x60x20(ag) | AG06012LB207300 | ◎● | 12 | 0.18 | 4500 | 21.419 | 0.203 | 33.1 | |
| 60x60x20(ag) | AG06012MB207300 | ◎● | 12 | 0.20 | 5000 | 25.000 | 0.260 | 38.6 | |
| 60x60x20(ag) | AG06012HB207300 | ◎● | 12 | 0.23 | 5500 | 29.140 | 0.323 | 40.8 | |
| 60x60x20(ag) | AG06012UB207300 | ◎● | 12 | 0.28 | 6000 | 30.500 | 0.370 | 43.5 | |
| 60x60x20(ag) | AG06024DB207300 | ◎● | 24 | 0.10 | 4000 | 19.753 | 0.170 | 31.8 | |
| 60x60x20(ag) | AG06024LB207300 | ◎● | 24 | 0.12 | 4500 | 22.741 | 0.213 | 35.4 | |
| 60x60x20(ag) | AG06024MB207300 | ◎● | 24 | 0.14 | 5000 | 24.600 | 0.261 | 38.6 | |
| 60x60x20(ag) | AG06024HB207300 | ◎● | 24 | 0.16 | 5500 | 29.140 | 0.323 | 40.8 | |
| 60x60x20(ag) | AG06024UB207300 | ◎● | 24 | 0.19 | 6000 | 30.815 | 0.340 | 41.3 | |
| 60x60x20(ag-2) | AG06012DX207600 | ◎● | 12 | 0.16 | 4000 | 19.728 | 0.164 | 33.1 | |
| 60x60x20(ag-2) | AG06012LX207600 | ◎● | 12 | 0.18 | 4500 | 22.741 | 0.213 | 35.4 | |
| 60x60x20(ag-2) | AG06012MX207600 | ◎● | 12 | 0.22 | 5000 | 25.321 | 0.261 | 38.6 | |
| 60x60x20(ag-2) | AG06012HX207600 | ◎● | 12 | 0.26 | 5500 | 29.140 | 0.323 | 40.8 | |
| 60x60x20(ag-2) | AG06012UX207600 | ◎● | 12 | 0.32 | 6000 | 30.815 | 0.370 | 43.2 | |
| 60x60x20(gl) | AD0605DB-C71GL | ◎※● | 5 | 0.07 | 3000 | 10.935 | 0.076 | 18.4 | |
| 60x60x20(gl) | AD0605LB-C71GL | ◎※● | 5 | 0.10 | 3500 | 12.995 | 0.101 | 23.6 | |
| 60x60x20(gl) | AD0605MB-C71GL | ◎※● | 5 | 0.13 | 3900 | 14.754 | 0.126 | 25.2 | |
| 60x60x20(gl) | AD0605HB-C71GL | ◎※● | 5 | 0.18 | 4500 | 17.664 | 0.169 | 30.2 | |
| 60x60x20(gl) | AD0605UB-C71GL | ◎※● | 5 | 0.23 | 5100 | 19.010 | 0.210 | 34.1 | |
| 60x60x20(gl) | AD0612DB-C71GL | ◎※● | 12 | 0.04 | 3000 | 10.935 | 0.076 | 18.4 | |
| 60x60x20(gl) | AD0612LB-C71GL | ◎※● | 12 | 0.05 | 3500 | 12.995 | 0.101 | 23.6 | |
| 60x60x20(gl) | AD0612MB-C71GL | ◎※● | 12 | 0.06 | 3900 | 14.754 | 0.126 | 25.2 | |
| 60x60x20(gl) | AD0612HB-C71GL | ◎※● | 12 | 0.08 | 4500 | 17.664 | 0.169 | 30.2 | |
| 60x60x20(gl) | AD0612UB-C71GL | ◎※● | 12 | 0.09 | 5100 | 19.014 | 0.211 | 34.1 | |
| 60x60x20(gl) | AD0612XB-C71GL | ◎※● | 12 | 0.13 | 6100 | 23.580 | 0.296 | 38.0 | |
| 60x60x20(gl) | AD0624LB-C71GL | ◎※● | 24 | 0.04 | 3500 | 13.000 | 0.100 | 23.6 | |
| 60x60x20(gl) | AD0624MB-C71GL | ◎※● | 24 | 0.05 | 3900 | 14.754 | 0.126 | 25.2 | |
| 60x60x20(gl) | AD0624HB-C71GL | ◎※● | 24 | 0.06 | 4500 | 17.664 | 0.169 | 30.2 | |
| 60x60x20(gl) | AD0624UB-C71GL | ◎※● | 24 | 0.07 | 5100 | 19.010 | 0.210 | 34.1 | |
| 60x60x20(gl-t) | AD0605DB-C70GL(T) | ◎※● | 5 | 0.07 | 3000 | 10.741 | 0.054 | 18.4 | |
| 60x60x20(gl-t) | AD0605LB-C70GL(T) | ◎※● | 5 | 0.12 | 3500 | 12.502 | 0.082 | 23.5 | |
| 60x60x20(gl-t) | AD0605MB-C70GL(T) | ◎※● | 5 | 0.16 | 3900 | 14.279 | 0.112 | 28.0 | |
| 60x60x20(gl-t) | AD0605HB-C70GL(T) | ◎※● | 5 | 0.18 | 4600 | 16.459 | 0.140 | 31.0 | |
| 60x60x20(gl-t) | AD0612DB-C70GL(T) | ◎※● | 12 | 0.05 | 3000 | 10.741 | 0.054 | 18.4 | |
| 60x60x20(gl-t) | AD0612LB-C70GL(T) | ◎※● | 12 | 0.06 | 3500 | 12.502 | 0.082 | 23.5 | |
| 60x60x20(gl-t) | AD0612MB-C70GL(T) | ◎※● | 12 | 0.08 | 3900 | 14.279 | 0.112 | 28.0 | |
| 60x60x20(gl-t) | AD0612HB-C70GL(T) | ◎※● | 12 | 0.10 | 4600 | 16.459 | 0.140 | 31.0 | |
| 60x60x20(gl-t) | AD0612UB-C70GL(T) | ◎※● | 12 | 0.13 | 5100 | 18.928 | 0.183 | 35.5 | |
| 60x60x20(gl-t) | AD0612XB-C70GL(T) | ◎※● | 12 | 0.20 | 6100 | 23.554 | 0.283 | 39.0 | |
| 60x60x20(gl-t) | AD0624LB-C70GL(T) | ◎※● | 24 | 0.04 | 3500 | 12.500 | 0.080 | 23.5 | |
| 60x60x20(gl-t) | AD0624MB-C70GL(T) | ◎※● | 24 | 0.04 | 3900 | 14.279 | 0.112 | 28.0 | |
| 60x60x20(gl-t) | AD0624HB-C70GL(T) | ◎※● | 24 | 0.05 | 4500 | 16.310 | 0.130 | 31.0 | |
Note：
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規電流值；若有進一步需求，請直接與浩禧業務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規電流值；若有進一步需求，請直接與浩禧業務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
