產品介紹
| Fan = DC-Fan | Size = 60x60x15 | Speed = | Flow = | Noise = |
| Bearing type: ◎=Ball ※=Sleeve ●=Hypro Bearing | |||||||||
| Frame Size | Model No | Bearing | Volt. (VAC) | Current (A) | Speed (rpm) | Air Flow (CFM) | Pressure (InAq) | Noise (dB/A) | |
| 60x60x15(ag) | AG06005DB159100 | ◎※● | 5 | 0.10 | 3000 | 13.134 | 0.076 | 21.0 |  |
| 60x60x15(ag) | AG06005LB159100 | ◎※● | 5 | 0.13 | 3500 | 14.817 | 0.100 | 25.3 | |
| 60x60x15(ag) | AG06005MB159100 | ◎※● | 5 | 0.19 | 4000 | 17.250 | 0.133 | 28.7 | |
| 60x60x15(ag) | AG06005HB159100 | ◎※● | 5 | 0.28 | 4500 | 20.390 | 0.163 | 32.1 | |
| 60x60x15(ag) | AG06012DB159100 | ◎※● | 12 | 0.04 | 3000 | 13.134 | 0.076 | 21.0 | |
| 60x60x15(ag) | AG06012LB159100 | ◎※● | 12 | 0.06 | 3500 | 14.817 | 0.100 | 25.3 | |
| 60x60x15(ag) | AG06012MB159100 | ◎※● | 12 | 0.08 | 4000 | 17.250 | 0.133 | 28.7 | |
| 60x60x15(ag) | AG06012HB159100 | ◎※● | 12 | 0.10 | 4500 | 20.390 | 0.163 | 32.1 | |
| 60x60x15(ag) | AG06012UB159100 | ◎※● | 12 | 0.14 | 5000 | 21.466 | 0.202 | 35.8 | |
| 60x60x15(ag) | AG06012XB159100 | ◎※● | 12 | 0.26 | 6000 | 27.013 | 0.286 | 40.7 | |
| 60x60x15(ag) | AG06024DB159100 | ◎※● | 24 | 0.04 | 3000 | 13.134 | 0.076 | 21.0 | |
| 60x60x15(ag) | AG06024LB159100 | ◎※● | 24 | 0.05 | 3500 | 14.817 | 0.100 | 25.3 | |
| 60x60x15(ag) | AG06024MB159100 | ◎※● | 24 | 0.07 | 4000 | 17.250 | 0.133 | 28.7 | |
| 60x60x15(ag) | AG06024HB159100 | ◎※● | 24 | 0.08 | 4500 | 20.390 | 0.163 | 32.1 | |
| 60x60x15(ag) | AG06024UB159100 | ◎※● | 24 | 0.10 | 5000 | 21.466 | 0.202 | 35.8 | |
| 60x60x15(gl-7) | AD0605LB-D70GL(T) | ◎※● | 5 | 0.10 | 3500 | 12.332 | 0.081 | 24.8 | |
| 60x60x15(gl-7) | AD0605MB-D70GL(T) | ◎※● | 5 | 0.18 | 3900 | 14.324 | 0.122 | 28.8 | |
| 60x60x15(gl-7) | AD0605HB-D70GL(T) | ◎※● | 5 | 0.19 | 4500 | 15.816 | 0.146 | 33.4 | |
| 60x60x15(gl-7) | AD0612DB-D70GL(T) | ◎※● | 12 | 0.06 | 3100 | 10.801 | 0.064 | 21.3 | |
| 60x60x15(gl-7) | AD0612LB-D70GL(T) | ◎※● | 12 | 0.07 | 3500 | 12.332 | 0.081 | 24.8 | |
| 60x60x15(gl-7) | AD0612MB-D70GL(T) | ◎※● | 12 | 0.08 | 3900 | 14.324 | 0.122 | 28.8 | |
| 60x60x15(gl-7) | AD0612HB-D70GL(T) | ◎※● | 12 | 0.09 | 4500 | 15.816 | 0.146 | 33.4 | |
| 60x60x15(gl-7) | AD0612UB-D70GL(T) | ◎※● | 12 | 0.12 | 5100 | 18.361 | 0.169 | 38.6 | |
| 60x60x15(gl-7) | AD0624LB-D70GL(T) | ◎※● | 24 | 0.03 | 3500 | 12.332 | 0.081 | 24.8 | |
| 60x60x15(gl-7) | AD0624MB-D70GL(T) | ◎※● | 24 | 0.04 | 3900 | 14.324 | 0.122 | 28.8 | |
| 60x60x15(gl-7) | AD0624HB-D70GL(T) | ◎※● | 24 | 0.05 | 4500 | 15.816 | 0.146 | 33.4 | |
| 60x60x15(gl-7) | AD0624UB-D70GL(T) | ◎※● | 24 | 0.06 | 5100 | 18.361 | 0.169 | 38.6 | |
| 60x60x15(t)-9 | AD0605DB-D90(T) | ◎※● | 5 | 0.09 | 3100 | 15.051 | 0.065 | 22.8 | |
| 60x60x15(t)-9 | AD0605LB-D90(T) | ◎※● | 5 | 0.17 | 3500 | 17.033 | 0.079 | 25.8 | |
| 60x60x15(t)-9 | AD0605MB-D90(T) | ◎※● | 5 | 0.20 | 3900 | 18.879 | 0.103 | 29.7 | |
| 60x60x15(t)-9 | AD0605HB-D90(T) | ◎※● | 5 | 0.23 | 4500 | 22.670 | 0.143 | 32.7 | |
| 60x60x15(t)-9 | AD0612DB-D90(T) | ◎※● | 12 | 0.06 | 3100 | 15.051 | 0.065 | 22.8 | |
| 60x60x15(t)-9 | AD0612LB-D90(T) | ◎※● | 12 | 0.08 | 3500 | 17.033 | 0.079 | 25.8 | |
| 60x60x15(t)-9 | AD0612MB-D90(T) | ◎※● | 12 | 0.13 | 3900 | 18.879 | 0.103 | 29.7 | |
| 60x60x15(t)-9 | AD0612HB-D90(T) | ◎※● | 12 | 0.17 | 4500 | 22.670 | 0.143 | 32.7 | |
| 60x60x15(t)-9 | AD0624LB-D90(T) | ◎※● | 24 | 0.04 | 3500 | 17.033 | 0.079 | 25.8 | |
| 60x60x15(t)-9 | AD0624MB-D90(T) | ◎※● | 24 | 0.06 | 3900 | 18.879 | 0.103 | 29.7 | |
| 60x60x15(t)-9 | AD0624HB-D90(T) | ◎※● | 24 | 0.08 | 4500 | 12.670 | 0.143 | 32.7 | |
Note：
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規電流值；若有進一步需求，請直接與浩禧業務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規電流值；若有進一步需求，請直接與浩禧業務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
